OEM Pure Sine Wave 3000 watt Off Grid MPPT Solar Inverter High Efficiency

Name: OEM Pure Sine Wave 3000 watt Off Grid MPPT Solar Inverter High Efficiency
Brand: ASGOFT
Price: 1 USD

Wholesale OEM Pure Sine Wave 3000 watt Off Grid MPPT Solar Inverter High Efficiency from china suppliers

Brand Name : ASGOFT

Model Number : ASI -L4830U60-145

Certification : IEC 62109,SAA,cETL,UL1741&CSA C22.2

Place of Origin : Guangdong

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000

Delivery Time : With 1~3 Weeks

Packaging Details : Strong carton package,Wooden crate

Rated Input Power : 3000W

Max.Peak Power : 6,000VA

Rated Input Voltage : 120Vac(K/N/PE single phase)

Frequency : 50Hz/ 60Hz

Output Voltage Waveform : Pure Sine Wave

Rated Battery Voltage : 48Vdc

Voltage Range : 40-60Vdc

Max.PV Array Power : 3400W

Contact Now

High Efficiency Pure Sine Wave 3kw Solar Inverter With Internal Fan Smart WiFi Remote Monitoring

Description:

High Efficiency Power Supply - ASGOFT inverters has industrial design with a modern aesthetic look and built with advanced MMPT with up to 99.9% efficiency.

Safe & Easy to use - 360 degress of security from hardware to software. Supporting for remote monitoring of operating parameters is its major feature, apart from this, it also has advantage of outputs high-quality pure sine wave AC power and reliable output for long periods at rated power. It's very easy to install and simple to use.

Features:

Stable pure sine wave inverter
Built-in MPPT solar controller
Configurable input voltage range for home applications via LCD setting
Configurable AC/solar charger priority via LCD setting
Smart WiFi remote monitoring(optional)

Specifications:

Models	ASI -L4830U60-145
AC Mode
Rated Input Power	3000W
Max.Peak Power	6,000VA
Rated Input Voltage	120Vac(K/N/PE single phase)
Load Capacity Of Motors	2HP
Frequency	50Hz/ 60Hz
Output Voltage Waveform	Pure Sine Wave
Parallel Capacity	NO
BATTERY
Battery Type	Li-ion/Lead-acid /User defined
Rated Battery Voltage	48Vdc
Voltage Range	40-60Vdc
Max.MPPT Charge Current	60A
Max.Mains/Generator Charging Current	40A
Max.Hybrid Charging Current	100A
PV INPUT
Num.of MPPT Trackers	1
Max.PV Array Power	3400W
Max.Input Current	40A
Max.Voltage Of Open Cuurent	145Vdc
MPPT Voltage Range	60-115Vdc
MAINS/GENERATOR INPUT
Input Voltage Range	90-140Vac
Frequency Range	50Hz/ 60Hz
Bypass Overload Current	40A
EFFICIENCY
MPPT Tracking Efficiency	99.90%
Max.Battery Inverter Efficiency	92%

Dimensions	378280103(1.20.90.3ft)
Weight	6.2kg(13.6lb)
Protection Degree	IP20,Indoor Only
Operating Temperature Range	-15°C-55°C (5°F-55°F)
Noise	<60dB
Cooling Method	Internal Fan
Warranty	1 Year
COMMUNICATION
Communication Interfaces	USB/RS485/Dry node control
External Modules(Optional)	WiFi/GPRS
CERTIFICATION
Safety	IEC 62109,SAA,cETL,UL1741&CSA C22.2
EMC	EN61000,FCC Part15 ClassB
RoHS	Yes

Product Details :

FAQ

1. Who are we? What we do?

We are based in Shenzhen, China, focus on ESS battery solution for clients all over the world.

There are high-profile R&D , top management and sales teams.

ODM/OEM is available.

2. How do we guarantee the product warranty?

There is 5 to 10 years' warranty period.

3.How long is the lead time of sample order and production order?

About 1-2 weeks for sample order.

About 2-4 weeks for production order.

4. How long is the shipment?

About 2 weeks via air,3-7 weeks via sea, depending on the destination.

5. How do we offer the after-sales service?

We're ready for 24/7 service.
